MX48IR-70 HDMI Matrix&4x4Group(HDMI&HDBaseT)
FX-MX48IR-70
1 Feature
l Incorporates HDBaseT technology
l Any Four Sources to Any Four Displays,Each port supports HDMI or DVI inputs.
l The four outputs are all include one HDMI-A output port and one HDBT output port,
They can output simultaneously
l Support high definition resolution 1080p,1080i,720p and standard video formats
l Extends HDMI up to 228 feet (70 meters) using one CAT5e (or better) cable
l Supports high bit-rate audio formats (Dolby True-HD / DTS Master Audio )
l Switching modes: panel buttons, local IR, RS232 and Ethernet
l IR system could control the source from the sinks or control the sinks from sources
l HDCP compliant.
l Support 3D.
l DC 12V Power supply.
l Power consumption:20watts
l Dimension (L×W×H):442.5x170x44.5 mm
l Net Weight:2450g .
2 SPECIFICATIONS
|
Operating Temperature Range |
-5 to +65℃(+23 to +149℉)
|
|
Operating Humidity Range |
5 to 90%RH (No Condensation) |
|
Video Bandwidth |
225MHz/6.75Gbps |
|
Support Video Format |
Up to 1080p@60Hz@36b/pixels,support 3D |
|
Connectors |
HDMI receptacle
RJ45
Power connector terminal
Power DC receptacle
IR Extender
|
|
Transmission Distance |
1080P 228FT/70m over single CAT5E/6 Solid
|
|
RJ45 Pin Configuration
Reverse Polarity Sensitive
Use EIA/TIA 568B
Straight-through wiring |
|
|
Power supply |
110-240V/DC 12V Power supply |
|
Power consumption |
20Watts |
|
Enclosure |
Cold-Rolled(Cold Rolled) Steel |
|
Dimension (L×W×H) |
442.5x170x44.5mm |
|
Net Weight |
2450g |
