    24 port HDMI smart matrix over cat5e/6 cable

    Item No.: FX-GES24
    Series: Product
    Category: HDMI extend through the optical fiber

    Consult

      • 24 port HDMI smart matrix over cat5e/6 cable
      • 24 port HDMI smart matrix over cat5e/6 cable
      • 24 port HDMI smart matrix over cat5e/6 cable
      Products Details Wiring diagram Manual download

      FX-GES24

      1 Feature

      l Gigabit Enthernet smart with 24 PCS RJ45 ports,each port can be set as input or output

      l Support default configuration which can be restored to overwrite the current configurantion whitch is working on via Web UI and Reset button of the switch.

      l Supports user managment and limits one user to login.

      l 8K MAC address.

      l Full-deplex flow(IEEE802.3x)and half-deplex backpressure.

      l Supports Unkown Unicast/Broadcast/Multicast Storm Control.

      l Power Consumption4.5W

      l Dimension (L×W×H):225x103x42mm

      l Net Weight:Receiver:1.02kg


      2 SPECIFICATIONS

      Operating Temperature Range

      -5 to +65℃(+23 to +149℉)

      Operating Humidity Range

      5 to 90%RH (No Condensation)

      Input Video Signal

      0.5-1.0 Volts P-P

      Input DDC Signal

      5 volts p-p(TTL)

      Support Video Format

      1080P

      Video Output

      HDMI

      Transmission Distance

      1080P 8-bit 120m over single CAT5E/6 /24AWG/Solid

      Power consumption

      4.5W

      IR frequency

      38kHz-56kHz

      Dimension (L×W×H)

      225x103x42mm

      Net Weight

      1.02kg
