Product
Audio Extender over Cat5e/6 Cable AEX300
FX-AEX300
Feature
1)Transmission Range: Up to 990ft (300 meters)
2) Accepts Digital Coax or Optical Toslink
3) Supports Digital 5.1 (DTS, Dolby Digital, etc.)
4)Data Transmission Rate: 12.8 Mb/s
5) S/PDIF (Digital Coax): 96 kHz performance
6)Power Supply DC5V/1A
7) Power Consumption：1watts
8) Dimension (L×W×H):TX/RX:60.5x46.5x20mm
9) Net Weight:150g(Pair)
SPECIFICATIONS
|
Operating Temperature Range |
-5 to +35℃(+23 to +95℉) |
|
Operating Humidity Range |
5 to 90%RH (No Condensation) |
|
Data transfer speed |
6.75Gbps |
|
Connectors Transmitter |
1xCat5e/6 out
1xPower DC
2xAudio in(for Optical and Coaxial) |
|
Connectors Receiver |
1xCat5e/6 in
2xAudio out(for Optical and Coaxial) |
|
Audio format |
Dolby 5.1, DTS Digital etc |
|
Power consumption |
1watts |
|
Dimension (L×W×H) |
60.5x46.5x20mm |
|
Net Weight |
150g(Pair) |
Note: Specifications are subject to change without notice. Mass and dimensions are approximate.
